Rockdoor Gearbox Split/Lever Lever Spindle 45mm Gearbox

Rockdoor locks are characterised by their central latch and deadbolt.The original Rockdoor multipoint lock, available with lift lever operation, split spindle or key wind.

We will configure the gear box for you.

Comes with Fixing pins

Product Specification

• Case Height: 185mm
• Case Width: 50mm
• Backset: 45mm
• Between spindle and euro cylinder: 92mm
• Latch to Hook bolt Centres: 90mm
• Spindle to Top of Gearbox: 63mm
• Secured by Design
• Tested to 100,000 cycles

Operation: Split Spindle

To unlock the door

1. Unlock the system by turning the key.

2. Push the handle downwards to disengage the locking points and retract the latch.

To lock the door

Use door locks on latch when shut to lock door fully.

1. Lift the handle upwards to engage the locking points.

2. Lock the locking points and main deadbolt (if present) by turning the key.

3. Turn key again 1/4 turn to retract latch

Operation: Lever/lever

To Lock:

1. Lift the handle up to engage the multipoint hooks/bolts.

2.Then turn the key to secure.

To Unlock/Open:

1.Insert the key, turn key.

2.Press the handle down to disengage locking points
